Cable, high voltage, 3 x 10mm2
Art nr. 1069886 (CS2437)
- 3 off 10.0 mm² EPR unsulated class 5 tinner copper conductor
Description
Electrical Characteristics:
- Core cross sectional area: 10.0 mm²
- Max conductor resistance @ 20°C: 1.95 Ω/km
- Voltage rating Uo/U(Um): 0.6/1.0 kVAC / 8.4 kVDC
- Voltage test duration: 5 minutes
- AC spark test voltage: 7 kV
- Current rating in free air @ 30°C: 75 A
- Insulation resistance @ 20°C, 500 VDC: > 621 MΩ*km
Cable attributes:
- Nominal overall diameter: 17.5 mm
- Nominal radial thickness of outer sheath: 2.25 mm
- Nominal laid up diameter of cable: 13.0 mm
- Weight of cable in air (approx.): 491 kg/km
- Weight of cable in seawater (approx.): 238 kg/km
- Weight of cable in freshwater (approx.): 244 kg/km
- Ambient operating temperature range: -20 to 80°C
- Maximum conductor temperature: 90°C
- Minimum recommended static bend radius: 140 mm
- Minimum recommended dynamic bend radius: 210 mm
- Maximum continuous length: 10,000 m
- Maximum hydrostatic working pressure: 350 BAR (TBC)
