Tritech AnchorZip 10 – Heavy Duty Suction Anchor Pump
The AnchorZip 10 is a heavy duty suction anchor pump designed for work vehicles able to produce 25 HP of hydraulic power.
Description
The AnchorZip 10 is a unique product which incorporates many technical advances developed from several years of producing and operating Tritech’s industry-standard range of ROV mounted jetting and excavation systems.
The AnchorZip 10 is specifically designed for ROV deployment and will interface with most work ROV hydraulic systems. ROV fitted with the new AnchorZip 10 pump will offer a very quick and cost effective way of installing and removing suction anchors. Output pressures may be regulated to ensure that differential pressures remain within the structural limits of all types of suction anchor. Flow reversal for anchor recovery is cleverly and simply achieved by sliding the motor and top assembly from the input to the output side of the centrifugal pump.
AnchorZip 10 pumps of other pressure and flow capacities can be built to order. Electrically powered systems are also available on request.
Technical information
Hydraulic Motor Input
Pressure: 276 Bar (4000 psi)
Flow: 70 litres per minute (15 USgpm)
Actuator
Minimum pressure: 70 Bar (1000 psi)
Maximum pressure: 240 Bar (3480 psi)
Hydraulic Fittings
Motor A & B: No. 12 JIC male
Motor case drain: No. 6 JIC male
Actuator connection: No. 4 JIC male
Output
Typical differential pressure: Up to 9.5 Bar (140 psi)
Typical suction flow: Up to 80 cubic metres per hour at 7.5 Bar
Nozzle and Hose Dimensions
Anchor port connection: Square flange with 72mm port
Minimum hose diameter: 72mm (2.8”)
Weight and Materials
Weight in air: 30kg (66lb)
Weight in water: 14kg (31lb)
Materials: Stainless steel, Nylacast, UHMWPE
